Synology FlashStation FS3600 – NAS server – 24 bays – rack-mountable – RAID RAID 0, 1, 5, 6, 10, JBOD, RAID F1 – RAM 16 GB – Gigabit Ethernet / 10 Gigabit Ethernet – iSCSI support – 2U

Descripción Corta:

Product Description: Synology FlashStation FS3600 – NAS server
Device Type: NAS server
Host Connectivity: Gigabit Ethernet / 10 Gigabit Ethernet
Enclosure Type: Rack-mountable – 2U
Installed Devices / Modules Qty: 0 (installed) / 24 (max)
Dimensions (WxDxH): 19 in x 28.5 in x 3.5 in
Weight: 32.85 lbs ()
Processor: 1 x Intel Xeon D-1567 2.1 GHz (12-core)
Storage Controller: RAID RAID RAID 0, 1, 5, 6, 10, JBOD, RAID F1
Networking: 10Mb LAN, 100Mb LAN, 1GbE, 10GbE
IP Cameras Supported: 128
RAM: 16 GB
Power: AC 120/230 V (50/60 Hz)
Manufacturer Warranty: 5-year warranty

Descripción Completa:

General:
Device Type: NAS server
Host Connectivity: Gigabit Ethernet / 10 Gigabit Ethernet
Enclosure Type: Rack-mountable – 2U
Total Storage Capacity: 0 GB
Installed Devices / Modules Qty: 0 (installed) / 24 (max)
Width: 19 in
Depth: 28.5 in
Height: 3.5 in
Weight: 32.85 lbs ()

Processor / Memory:
Processors Installed: 1 x Intel Xeon D-1567 2.1 GHz
Number of Cores: 12-core
Max Supported Qty: 1
Max Turbo Speed: 2.7 GHz
RAM: 16 GB (installed) / 128 GB (supported) – DDR4
Features: Registered, ECC

Storage Controller:
Type: RAID
RAID Level: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD, RAID F1

Networking:
Data Link Protocol: 10Mb LAN, 100Mb LAN, 1GbE, 10GbE
Network / Transport Protocol: PPTP, L2TP, iSCSI, SMTP, FTP, SMB, NFS, HTTPs
Remote Management Protocol: SNMP, Telnet, HTTPS, SSH, SMTP, LDAP
Network Services Compatibility: Microsoft Active Directory (AD), Network File System (NFS), FTP, Server Message Block (SMB), Apple File Protocol (AFP), HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV)
Features: Firewall protection, VPN support, LDAP support, wake on LAN (WOL), antivirus analysis, High Availability, anti-malware protection, Access Control List (ACL) support, e-mail server, reset button, bandwidth control, surveillance station, VPN Server, Link Aggregation, failover protection, OpenStack compatible, B-tree file system (Btrfs), file station, EXT4 file system, iSCSI LUN clone/snapshot, Windows ODX, MailPlus server
Encryption Algorithm: AES-NI

Security DVR:
IP Cameras Supported: 128
Compression Format: MJPEG, H.264, H.265
Image Resolution: 1280×720, 1920×1080, 2048×1536, 2591×1944, 3840×2160

Expansion / Connectivity:
Expansion Bays: 24 (total) / 24 (free) x hot-swap – 2.5″
Expansion Slots: 1 x PCI Express 3.0 x8 ¦ 4 (total) / 3 (free) x DIMM 288-pin
Interfaces: 4 x Ethernet 1000Base-T – RJ-45 ¦ 2 x USB 3.0 – Type A ¦ 1 x serial – DB-9 ¦ 2 x Ethernet 10Gb – RJ-45

Miscellaneous:
Features: Built-in 4 cooling fans
Compliant Standards: VCCI, BSMI, FCC, RoHS, EAC, RCM
Included Accessories: Accessory pack

Power:
Power Device: Internal power supply
Installed Qty: 2
Max Supported Qty: 2
Voltage Required: AC 120/230 V (50/60 Hz)
Power Consumption Operational: 258.23 Watt
Power Provided: 500 Watt

Manufacturer Warranty:
Service & Support: Limited warranty – 5 years

Environmental Parameters:
Min Operating Temperature: 32 °F
Max Operating Temperature: 95 °F
Humidity Range Operating: 5 – 95%
Sound Emission: 57 dBA
