Supermicro SuperStorage Server 2027R-E1R24L – Server – rack-mountable – 2U – 2-way – no CPU – RAM 0 GB – SAS – hot-swap 2.5″ bay(s) – no HDD – G200eW – GigE – monitor: none – black

Descripción Corta:

Product Description: Supermicro SuperStorage Server 2027R-E1R24L – rack-mountable – no CPU – 0 GB – no HDD
Type: Server – rack-mountable
Height (Rack Units): 2U
Server Scalability: 2-way
Processor: No CPU
Processor Socket: LGA2011 Socket
RAM: 0 GB (installed) / 512 GB (max) – DDR3 SDRAM – ECC
Storage Controller: RAID (SATA 6Gb/s / SATA 3Gb/s); SAS-2 (SAS 6Gb/s) (LSISAS2308)
Server Storage Bays: Hot-swap 2.5″
Hard Drive: No HDD
Optical Storage: No optical drive
Graphics Controller: Matrox G200eW
Networking: GigE
Power: AC 120/230 V (50/60 Hz)
Power Redundancy: Yes
Color: Black
Dimensions (WxDxH): 17.2 in x 24.8 in x 3.5 in
Manufacturer Warranty: Limited warranty – labor – 3 years ¦ Limited warranty – parts – 1 year

Descripción Completa:

General:
Type: Server
Product Form Factor: Rack-mountable – 2U
Server Scalability: 2-way
Hot-Swap Bays Qty: 24
Color: Black

Processor / Chipset:
CPU: No CPU
Max CPU Qty: 2
CPU Upgradability: Upgradable
CPU Socket: LGA2011 Socket
Chipset Type: Intel C602J

RAM:
Installed Size: 0 GB / 512 GB (max)
Technology: DDR3 SDRAM – ECC
Form Factor: DIMM 240-pin
Slots: 16 (total) / 16 (empty)
Features: Unbuffered, registered
RAM Supported: 512 GB registered – ECC ¦ 128 GB unbuffered – ECC

Hard Drive:
Type: No HDD

Storage Controller:
Type: 1 x RAID – integrated
Controller Interface Type: SATA 6Gb/s / SATA 3Gb/s
Channel Qty: 6
RAID Level: RAID 0, RAID 1, RAID 5, RAID 10

Storage Controller (2nd):
Type: 1 x SAS-2 – integrated
Controller Interface Type: SAS 6Gb/s
Storage Controller Name: LSISAS2308
Channel Qty: 8

Optical Storage:
Type: No optical drive

Monitor:
Monitor Type: None.

Graphics Controller:
Type: Integrated
Graphics Processor: Matrox G200eW
Video Interfaces: VGA

Networking:
Type: Integrated
Ethernet Ports: 4 x Gigabit Ethernet
Ethernet Controller: Intel I350
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol: IPMI 2.0
Features: KVM over IP support

Expansion / Connectivity:
Bays: 24 (total) / 24 (free) x hot-swap 2.5″
Slots: 2 (total) / 2 (free) x CPU ¦ 16 (total) / 16 (free) x DIMM 240-pin ¦ 5 (total) / 5 (free) x PCIe 3.0 x8 – low-profile
Interfaces: 4 x LAN (Gigabit Ethernet) ¦ 5 x USB 2.0 (1 internal) ¦ 1 x VGA ¦ 1 x serial ¦ 1 x management

Miscellaneous:
Included Accessories: 2 x CPU Heatsink
Compliant Standards: Plug and Play, ACPI 2.0, APM 1.2, RoHS

Power:
Device Type: Power supply
Power Redundancy: Yes
Power Redundancy Scheme: 1+1
Installed Qty: 2
Max Supported Qty: 2
Voltage Required: AC 120/230 V (50/60 Hz)
Power Provided: 920 Watt
80 PLUS Certification: 80 PLUS Platinum

Manufacturer Warranty:
Service & Support: Limited warranty – labor – 3 years ¦ Limited warranty – parts – 1 year

Dimensions & Weight:
Width: 17.2 in
Depth: 24.8 in
Height: 3.5 in

Environmental Parameters:
Min Operating Temperature: 50 °F
Max Operating Temperature: 95 °F
Humidity Range Operating: 8 – 90% (non-condensing)
