Seasonic ATX ES2 SSP-500ES2 – Power supply (internal) – ATX12V 2.3 – 80 PLUS Bronze – AC 100-240 V – 500 Watt – active PFC

Descripción Corta:

Product Description: Seasonic ATX ES2 SSP-500ES2 – power supply – 500 Watt
Device Type: Power supply – active Power Factor Correction (PFC) – internal
Specification Compliance: ATX12V 2.3
80 PLUS Certification: 80 PLUS Bronze
Input Voltage: AC 100-240 V
Output Voltage: +3.3, +5, ±12 V
Power Capacity: 500 Watt
Output Current: +3.3V – 24 A ¦ +5V – 24 A ¦ +12V1 – 18 A ¦ +12V2 – 18 A ¦ -12V – 0.3 A ¦ +5VSB – 2.5 A
Output connectors: 15 pin Serial ATA power ¦ 4 pin internal power ¦ 4 pin mini-power connector
Cooling System: 80 mm fan
Dimensions (WxDxH): 5.9 in x 5.5 in x 3.4 in

Descripción Completa:

General:
Device Type: Power supply – active Power Factor Correction (PFC) – internal
Specification Compliance: ATX12V 2.3
PSU Form Factor: ATX

Power Device:
Input Voltage: AC 100-240 V
Frequency Required: 50/60 Hz
Power Output Connectors Details: 15 pin Serial ATA power ¦ 4 pin internal power ¦ 4 pin mini-power connector
Output Voltage: +3.3, +5, ±12 V
Power Capacity: 500 Watt
Output Current: +3.3V – 24 A ¦ +5V – 24 A ¦ +12V1 – 18 A ¦ +12V2 – 18 A ¦ -12V – 0.3 A ¦ +5VSB – 2.5 A
Power Factor (PF): 0.99
80 PLUS Certification: 80 PLUS Bronze

Miscellaneous:
MTBF: 100,000 hours
Cooling System: 80 mm fan
Features: On/off switch, overvoltage protection, overpower protection, short-circuit protection, dual ball bearing cooling fan, non-modular, Seasonic S2FC fan Control
Compliant Standards: TUV, BSMI, CB, CCC, FCC, cTUVus, RCM, IEC 62368-1, ErP Lot 6 2013 Ready

Dimensions & Weight:
Width: 5.9 in
Depth: 5.5 in
Height: 3.4 in
